Litrax TWO (L2) -
pyrolized thermo
bamboo
Pyrolized thermo bamboo -
Litrax TWO series
Key facts and advantage:
-
Quick and high insulation from 0.8 to 3.2 Clo
-
Rapid warming effect up to +28°C
and beyond
-
Rapid increase of local blood circulation
-
High deodorizing effect due to porous bamboo
-
Excellent for underwear, pyjamas
or sports clothing
-
Thermo bamboo keeps dry in summer & during sports
-
Blending possible (intimate
fiber or yarn mix)
-
Thin padded winter jackets with high insulation
capacity
-
Antibacterial according to JIS standard L1902-1998
-
Far Infrared absorption
-
Excellent Ultraviolet Protection (UPF 25)
-
Negative Ions (580 counts/cc)
Frequently asked questions FAQ
-
How well does LITRAX TWO Thermo
bamboo insulate?
LITRAX TWO THERMO BAMBOO provides exceptional clothing insulation properties
in terms of the standard textile thermal insulation unit (clo unit). LITRAX TWO THERMO BAMBOO fibers can insulate from 0.8 to over 3.9 Clo, a unit of thermal insulation used
for clothing. which can be projected in to a massive and unprecedented ~27.5°Celsius of raised temperature. The amount of insulation required to keep a resting person warm in a
windless room at 70 °F (21.1 °C) is equal to 1 Clo.
-
How to test insulation?
EN13537 and ASTM1518-1985 methods, or with a thermo camera (for coloured effects)
-
What does the Clo unit mean?
The clo is a measure of thermal resistance. It measures the insulation provided by any layer
of trapped air between skin and clothing and the insulation value of the clothing itself. 1 clo unit will maintain a sedentary man comfortable indefinitely in an environment of 21°C (70°F), 50% relative humidity, and 0.01 m/s (20 ft/min) air movement. Assuming no wind penetration and no body movements to pump air around, clothing insulation = 0.15 x
weight of clothes in lbs. (i.e., 0.15 clo per lb of clothes). So 10 lbs. clothes = 1.5 clo. A thick business suit provides an average of approximately 1 clo of intrinsic insulation for the whole body. Common textiles such as shirts and pullovers display values between 0.5 - 1.1 clo
while standard insulation values of bedding can be between 1.4 and 1.6 clo.
LITRAX TWO THERMO BAMBOO fibers insulate up to 3.2 Clo with fiber padding (filling of jackets, shoes) and could also be used for enhanced construction insulation.
You can download the complete fact
sheet and some additional yarn information
in PDF form
Available products:
Litrax Two L2
– pyrolized thermo bamboo - fibers
|
Art.
descr
|
Dtex
|
Cut mm
|
type
|
Info
|
|
sd.rd
|
1.7
|
38
|
L2
PET
|
for
ring spinning
|
|
sd.rd
|
2.2
|
22
|
L2
PET balls
|
for
filling
|
|
sd.rd
|
2.2
|
88
|
L2
PET
|
for
worsted spinning
|
|
sd.rd
|
2.2
|
88
|
L2
recycl. PET
|
for
worsted spinning
|
|
sd.rd
|
7.7
|
64
|
L2
PET
|
|
Litrax Two L2 – pyrolized thermo bamboo - Spun Yarn
|
dtex single
|
Count Nm
|
Count ECC
|
|
|
|
118
|
85/1
|
50/1
|
ring
|
60/40% comb.Mako CO/ PET L2
|
|
118
|
85/1
|
50/1
|
ring
|
60/40% comb.CO/PET L2
|
|
148
|
68/1
|
40/1
|
ring
|
60/40% comb.CO/PET L2
|
|
197
|
50/1
|
30/1
|
ring
|
60/40% comb.US CO/PET L2
|
|
197
|
50/1
|
30/1
|
ring
|
60/40% comb.CO/PET L2
|
|
197
|
50/1
|
30/1
|
ring
|
60/40% CV/PET L2
|
|
295
|
34/1
|
20/1
|
ring
|
60/40% comb.CO/PET L2
|
|
295
|
34/1
|
20/1
|
ring
|
60/40% CV/PET L2
|
Litrax Two L2 – pyrolized filament thermo bamboo
|
Art.
Descr
|
Dtex
|
Fil
|
twist
direct.
|
Ply
|
Base
material
|
text
|
Info
|
|
sd.rd
|
44
|
14
|
0
|
|
PA6
|
flat
HOY
|
nano
silver anti bacteria
|
|
sd.rd
|
44
|
36
|
(S)
|
x 1
|
PET
|
SET
|
|
|
sd.rd
|
56
|
24
|
(S)+(Z)
|
x 1
|
PA6
|
HE
|
|
|
sd.rd
|
56
|
24
|
(S)+(Z)
|
x 1
|
PA6
|
HE
|
nano
silver anti bacteria
|
|
sd.rd
|
56
|
72
|
(S)
|
x 1
|
recycled
PET
|
SET
|
|
|
sd.rd
|
78
|
48
|
0
|
|
PA6
|
flat
HOY
|
|
|
sd.rd
|
78
|
48
|
0
|
|
PA6
|
flat
HOY
|
nano
silver anti bacteria
|
|
sd.rd
|
78
|
48
|
(S)+(Z)
|
x 1
|
PA6
|
HE
|
|
|
sd.rd
|
78
|
48
|
(S)+(Z)
|
x 1
|
PA6
|
HE
|
nano
silver anti bacteria
|
|
sd.rd
|
84
|
48
|
(S)
|
x 1
|
PET
|
SET
|
|
|
sd.rd
|
84
|
48
|
(S)
|
x 1
|
recycled
PET
|
SET
|
|
|
br.tr
|
84
|
72
|
(S)
|
x 1
|
PET
|
SET
|
nano
silver anti bacteria
|
|
br.rd
|
84
|
72
|
(S)
|
x 1
|
recycled
PET
|
SET
|
|
|
sd.rd
|
84
|
72
|
(S)+(Z)
|
x 1
|
PET
|
SET
|
|
|
sd.rd
|
84
|
72
|
(S)+(Z)
|
x 1
|
PET
|
SET
|
black
high temp. L2
|
|
sd.rd
|
84
|
72
|
(S)
|
x 1
|
PET
|
SET
|
nano
silver anti bacteria
|
|
sd.rd
|
84
|
72
|
(S)
|
x 1
|
recycled
PET
|
SET
|
|
|
sd.rd
|
84
|
72
|
(S)
|
x 1
|
recycled
PET
|
SET
|
black
high temp. h. load L2
|
|
sd.rd
|
84
|
144
|
(S)
|
x 1
|
recycled
PET
|
SET
|
|
|
sd.rd
|
110
|
48
|
(S)
|
x 1
|
recycled
PET
|
SET
|
|
|
br.rd
|
167
|
48
|
(S)
|
x 1
|
recycled
PET
|
SET
|
|
|
br.rd
|
167
|
144
|
(S)
|
x 1
|
recycled
PET
|
SET
|
|
|
sd.rd
|
167
|
144
|
(S)
|
x 1
|
PET
|
SET
|
nano
silver anti bacteria
|
|
sd.rd
|
167
|
144
|
(S)
|
x 1
|
recycled
PET
|
SET
|
|
|
sd.rd
|
167
|
288
|
(S)
|
x 1
|
recycled
PET
|
SET
|
|
|
br.rd
|
330
|
95
|
(S)
|
x 1
|
recycled
PET
|
SET
|
|
Semi-finished products Litrax Two L2 – pyrolized thermo bamboo
|
type
|
Wt
g/m2
|
Width
cm
|
CLO value
|
raisg.
temp. °C
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
